Benka Loose Tube Armoured Fiber Optic Cable

Benka Loose Tube Armoured Fiber Optic Cable

Giá:
Liên hệ

Simplify your network installation, whether indoors or outdoors with our indoor/outdoor loose tube fiber cable. Its crush-resistant design thoroughly protects data connection.

Liên hệ tư vấn

Construction

Fiber count 02-72 cores (up to 144 cores)
Fiber type Single mode or multi-mode
Cable type IIndoor/outdoor armored loose tube
Water proof Thixotropic jelly gel-filled
Strength member Aramid yarn/FRP
Armor Corrugated steel tape
Outer sheath PE/LSZH
Sheath color Black
Coating color ANSI/TIA-598
Smoke density IEC 61034-2
Halogen free IEC 60754-1
Rated temperature -20°C to +70°C
Flame retardant  UL 1685, IEC
Water penetration IEC 60794-1-2-F5B
Torsion IEC 60794-1-2-E7
Cable kink IEC 60794-1-2-E10
Standard & Approval IEC, ITU, EIA, RoHS, SIRIM

Fiber Transmission Performance

Cable optical fiber OS2 OM2 OM3 OM4
Wave length (nm) 1310/1550 850/1300 850/1300 850/1300
Wave length (nm)   500/500 1500/500 3500/500
Max attenuation (dB/km) 0.4/0.3 3.5/1.5 3.0/1.5 3.0/1.5

Technical Data

Fiber count Cable dimension
 (mm)		 Tensile strength
 (N)		 Crush resistance
 (N/100mm)		 Minimum bending radius
 (mm)
    Short term Long term   Dynamic Static
2-12 9.1 ± 1.0 1500 600 1000 182 91
16-24 11.6 ± 1.0 2700 890 2200 232 116
36-72 11.6 ± 1.0 2700 890 2200 232 116
